Metal Chassis •Steel top and bottom •Aluminum side panels Polytouch® Keybed •49 keys, semi-weighted •Polyphonic aftertouch •Selectable velocity/aftertouch curves 4-octave Ribbon Controller (67 cm, 26.4”) •Pitch Bend mode •Mod Only mode – use the ribbon as a modulation source •Theremin mode - the ribbon triggers a note ◦Choose continuous pitch or one of 60 scales, including microtonal ◦Selectable range: 2, 4, or 6 octaves •Ribbon can be CV source Additional Hardware Controls •Octave Up/Down buttons for instant transposition •Chord mode button: stack up to 8 notes in a chord •Pitch bend/modulation controls with adjustable depth Patch Memory •8 banks with 128 patches each: 1,024 total •Sort patches by Patch number, Name, or Category •Browse Favorites: Select 32 patches from any bank for immediate access CV / Gate Inputs and Outputs •Supports multiple CV / Gate standards ◦CV -1v per octave 0-10V -1v per octave +/-5V -Hz to Volts 0-10V -1.2V per octave -Adjustable offset: +/-99 cents -Adjustable reference note: C-1 to G9 ◦Gate -V-trig, S-trig -3V, 5V, 10V ◦Mod In / Out range -+/-5V, 0-10V, 0-5V, 0-1V -Adjustable offset: +/-3V ◦Clock Out -1PPS, 2PPQ, 24PPQ, 48 PPQ -Clock Voltage: 3v, 5V, 10V -Selectable clock division: Off, 1/2, 2, 4 -Adjustable offset: +/- 100ms MIDI IN / OUT / THRU •Voice overflow mode to expand polyphony with a second Hydrasynth Expression pedal input •Selectable curves and polarity Sustain pedal input •Polarity sensing •Three modes of operation: Sustain, Sostenuto, and Modulation Only DC input jack USB port •Supports USB MIDI In / Out Audio outputs •Stereo analog outputs (balanced) •Two headphone connectors ◦6.35 mm (1⁄4 inch) and 3.5 mm ◦Shared volume control ◦Impedance: 16 – 75 Ohm Dimensions •80 x 35 x 10.3 cm (31.5 x 13.78 x 4.05 inches) Weight •10kg (22.05 lbs) Sound Patch Specifications 8 Voice Advanced Wavetable synthesis Oscillators 1 and 2: Wavemorphing oscillators •219 single-cycle waveforms •User wavetables ◦8 user-selectable waves per oscillator to build custom wavetables ◦WaveScan parameter lets you morph through the wavetables ◦Every patch can have two unique wavetables •Bit reduction: 11 settings from 2 to 16 bits, and Off •+/- 3 octave tuning range •Keytracking: 0-200% Oscillator 3: fixed Wave oscillator •219 single-cycle waveforms •Bit reduction: 11 settings from 2 to 16 bits, and Off •+/- 3 octave tuning range •Keytracking: 0-200% Dual Mutants per oscillator (Osc 1 and 2) •FM: Linear FM ◦Selectable Modulator source: -Internal Sine & Triangle waves, Oscillators 1-3, Ring Mod, Noise generator, Mutants 1-4, External Mod inputs 1 & 2 •WavStack™: Generates 5 detuned waves from the input source, with an adjustable detune amount •Hard Sync (Osc Sync): gives that classic sync sweep sound ◦Selectable sync input source: Oscillators 1-3 ◦Adjustable Hann window to shape the output •Pulse Width Modulation (PW-Orig): Adjusts the pulse width of any waveform •PW-Squeeze: Compresses the center section of the waveform, for a unique type of PWM •PW-ASM: 8 adjustable Warp points can be applied to the waveform, for a unique form of FM synthesis ◦Warp points can be modulated individually through the Mod Matrix •Harmonic Sweep: scans through the harmonics of the incoming waveform •PhazDiff: creates a new sound by combining phase shifting and summing techniques •Depth control for all Mutants •FeedBack control for all Mutants (except WavStack): 0-150% •Ratio control for Osc Sync, Harmonic, and all PWM Mutants: 0.250:1 - 64:1 ◦Mutations occur up to 64 times in one waveform cycle, or as few as once in four cycles •Dry/Wet mix to blend the input source with the Mutant output Noise Generator •White, Pink, Brown, Red, Blue, Violet, and Grey noise sources Ring Modulator •Selectable input source: ◦Oscillators 1-3, Noise, Mutants 1-4, External Mod inputs 1 & 2 •Depth control Sound source mixer •Independent level control for Oscillators 1-3, Noise, and Ring Mod •Panning for each source •Filter routing mix •Each source can be soloed ◦Solo status is saved with the patch Two Filters •Series or parallel r
